Description
QNAP TS-433-4G 4-Bay Diskless NAS ARM Cortex-A55 Quad-Core 2GHz 4GB
QNAP TS-433-4G - TS-433-4G ARM 4-core Cortex-A55 2.0 GHz
Run your own personal cloud storage and enjoy easy file access, sharing, and synchronization with TS-433.
The TS-433 is designed with a 2.5GbE port to enhance collaboration and increase remote work productivity.
It also offers rich multimedia applications and is a complete home entertainment portal.
- ARM 4-core Cortex-A55 2.0GHz processor
- System memory 4 GB, not expandable
- 4x 3.5-inch SATA 6Gb/s, 3Gb/s
- 1x 2.5 Gigabit Ethernet port (2.5G/1G/100M)
- 2x USB 2.0 port
- 1x USB 3.2 Gen 1 port
Centralized multimedia management
Centralized storage of photos, music, and videos; easily browse, organize, and share multimedia files.
AI-powered image recognition
With the built-in NPU (Neural Network Processing Unit) processor, TS-433 boosts performance for fast face and object recognition.
Home Entertainment Center
Supports ARM NEON technology, which accelerates video processing for a better entertainment experience.
Secure Remote Access
myQNAPcloud allows you to easily access, manage, and share NAS files over the Internet.
Snapshot protection against ransomware
Protect your files and data from accidental deletion and malware attacks by using advanced snapshot protection.
Comprehensive security management
Serves as a secure private cloud and supports user account protection, IP blocking, 2-step verification, encrypted access, and more
Minimalist Design
The compact and sleek TS-433 features a clean and essential design that fits perfectly in your home or office.
The design also extends to the hard drives, which can be installed without a screwdriver.
Effective cooling fan for heat flow
The TS-433 is small in size and stays powerful, cool and quiet thanks to an effective fan.
Build a 2.5GbE high-speed network environment
QNAP offers comprehensive, budget-friendly storage and networking solutions that provide a wide range of connectivity options.
Now upgrade your work or home network with ease and flexibility to handle bandwidth-intensive applications.
Package contents
1x TS-433
1x Ethernet cable
1x AC adapter
1x power cable
16x hard disk screws (3,5")
12x hard disk screws (2,5")
2x insertion wrench
1x manual
Hardware Specs
CPU
ARM 4-core Cortex-A55 2.0GHz processor
CPU Architecture
64-bit ARM
Floating Point Unit
Yes
Encryption Engine
Yes
System Memory
4 GB on board (non-expandable)
Note: Reserves some RAM for use as shared graphics memory.
Maximum Memory
4 GB on board (non-expandable)
Flash Memory
4 GB (Dual boot OS protection)
Drive Bay
4x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable
Yes
Gigabit Ethernet Port (RJ45)
1
2.5 Gigabit Ethernet Port (2.5G/1G/100M)
1 (2.5G/1G/100M)
Wake on LAN (WOL)
Yes
Jumbo Frame
Yes
USB 2.0 port
2
USB 3.2 Gen 1 port
1
Form Factor
Tower
LED Indicators
System Status, LAN, USB, HDD1~4
Buttons
Power, Reset, USB Copy
Dimensions (HxWxD)
169 × 160 × 219 mm
Weight (Net)
2.07 kg
Weight (Gross)
3.5 kg
Operating Temperature
0 - 40 °C (32°F - 104°F)
Storage Temperature
-20 - 70°C (-4°F - 158°F)
Relative Humidity
5-95% RH non-condensing, wet bulb: 27°C (80.6°F)
Power Supply Unit
90W adapter (12VDC), 100-240VAC
Power Consumption: HDD Sleep Mode
8.45 W
Power Consumption: Operating Mode, Typical
22.54 W
Tested with drives fully populated.
Fan
1 x 120mm, 12VDC
System Warning
Buzzer
Kensington Security Slot
Yes
Max. Number of Concurrent Connections (CIFS) - with Max. Memory
200
Software Specs
Operating System
QTS 5.0.1
Supported Client Operating Systems
Apple Mac OS 10.10 or later
Ubuntu 14.04, CentOS 7, RHEL 6.6, SUSE 12 or later Linux
IBM AIX 7, Solaris 10 or later UNIX
Microsoft Windows 7, 8, 10 and 11
Microsoft Windows Server 2008 R2, 2012, 2012 R2, 2016, and 2019
Supported Browsers
