Description
Logitech Room Scheduling Touch Screen - Graphite 952-000091
| · Pick your Platform |
| · Clean and Convenient Setup |
| · Anti-fingerprint |
| · Availability lighting |
| · Flat angle for accessibility |
Tap Scheduler makes it easy to see meeting details and reserve a room for ad hoc or future meetings. Easily deploy as a purpose-built scheduling panel for leading room scheduling solutions to help workers find and claim the right space.
RIGHT PLACE, RIGHT TIME
Tap Scheduler makes it easy to see meeting details and reserve a room for ad hoc or future meetings. Easily deploy as a purpose-built scheduling panel for leading room scheduling solutions to help workers find and claim the right space.
GREEN MEANS GO
Quickly find an open room through coloured LED lights that show availability at a distance.
CLEAN AND EASY INSTALL
Included mounts and clean cabling help ensure a tidy and professional setup.
Secure Tap Scheduler while maintaining a clean look on both sides of the glass.
PURPOSE-BUILT AS A SCHEDULING PANEL
Tap Scheduler was designed for easy viewing and usability, with a spacious screen and a sleek, unobtrusive profile. Count on Tap Scheduler for reliable performance with durable components that are built to last.
MAKE THE MOST OF YOUR SPACE
Easily add Tap Scheduler to a variety of meeting rooms, from phone booths to video rooms to hangout nooks, helping employees quickly find the right meeting location. Simple installations and an intuitive user experience drive fast deployment and adoption.
PAIRS WELL WITH PARTNERS
Enable easy and effective meetings for onsite and remote workers. Tap IP and the Logitech suite of room solutions integrate with leading video conferencing services for a seamless meeting experience.1
SIMPLE TO MANAGE WITH LOGITECH SYNC
With Logitech Sync, you can monitor and manage Tap Scheduler along with your other meeting room devices from one single platform.
SPECS & DETAILS
TECHNICAL SPECIFICATIONS
Screen
Size: 10.1” diagonal
IPS (In-Plane Switching)
LCD Panel with LED Backlighting
Resolution: 1280 x 800 resolution
Touch: Capacitive, 10 points multi-touch
Brightness: 400 nits
Contrast: 1000:1
Anti Fingerprint: Oleophobic coating
Viewing angle: 85 degrees (U/D/L/R)
Position angle: 0 degrees (flat on mounting surface)
GENERAL SPECIFICATIONS
Integrated accelerometer
Integrated ambient light sensor
100 mm x 100 mm VESA FDMI
Cable exits: horizontal / vertical / centre
COMPATIBILITY AND CERTIFICATIONS
Logitech Tap Scheduler integrates with leading room scheduling solutions as a
• Microsoft Teams Panel
• Zoom Rooms Scheduling Display
• Robin-Powered scheduling panel
• Meetio scheduling panel
See www.logitech.com/support/tapscheduler-compatibility for the latest certification and compatibility information.
Logitech CollabOS platform
Logitech Sync Remote Management
Power and Cables
Power over Ethernet (PoE), IEEE 802.3af Type 1, Class 3 device*
*Requires PoE enabled network or PoE Injector and ethernet cable (Not included)
PORTS AND INTERFACES
Ethernet: 10/100 Mbps
WiFi: 802.11a/b/g/n/ac
Bluetooth 5.0 (inactive, reserved for future use)
Environmental
Operating Temperature: 0 to 40°C
Stored Temperature: -40 to 70°C
Humidity: 10 to 95%
Security
Full Disk Encryption: AES-128
Data Encryption: Symmetric Keys, PKI
Device Identity: Protected by device attestation
Key Protection: Arm TrustZone, RPMP
DIMENSIONS
Device-only
Height: 165 mm
Width: 246.2 mm
Depth: 28.5 mm
Weight: 0.7 kg
Surface-mounted
Height: 165 mm
Width: 246.2 mm
Depth: 31.4 mm
Mullion-mounted
Height: 165 mm
Width: 292.6 mm
Depth: 44.5 mm
PACKAGE CONTENTS
Logitech Tap Scheduler
Multi-surface mount (glass/drywall)
Corner mount accessory
Mullion mount
Mounting hardware
Documentation
WARRANTY INFORMATION
Ensure peace of mind with an extended warranty for Tap Scheduler, adding one additional year to the standard two-year limited hardware warranty.
Contact your reseller for availability.
PART NUMBER
Graphite: 952-000091
White: 952-000094
