QNAP TS-673A-8G Business 6-Bay Desktop NAS Ryzen Embedded V1500B 4-Core 8 GB

QNAP TS-673A-8G Business 6-Bay Desktop NAS Ryzen Embedded V1500B 4-Core 8 GB

TS-673A
AMD Ryzen™ quad-core 2.2 GHz 2.5GbE NAS supports M.2 NVMe SSD and PCIe expansion for adding 10GbE high-speed connectivity and M.2 SSD; QTS and QuTS hero dual operating system for greater flexibility.

Featuring an AMD Ryzen™ V1000 series V1500B quad-core processor that delivers great system performance with up to quad-core / 8 threads and Turbo Core up to 2.2 GHz. The TS-673A features two 2.5GbE RJ45 ports and two PCIe Gen 3 slots for you to flexibly deploy 5GbE/10GbE networks. Two M.2 NVMe SSD slots for Qtier Technology and SSD Caching enable constant storage optimization. The TS-673A supports QTS and QuTS hero, allowing users to flexibly switch operating system based on their requirements.

CPU

AMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor

CPU Architecture

64-bit x86

Graphic Processors

Optional via a PCIe adapter

Floating Point

Unit

Encryption Engine

(AES-NI)

Hardware-accelerated Transcoding

Optional via a PCIe adapter

System Memory

8 GB SO-DIMM DDR4 (1 x 8 GB)

Maximum Memory

64 GB (2 x 32 GB)

Memory Slot

2 x SO-DIMM DDR4

Support ECC memory

For dual-DIMM configurations, you must use a pair of identical DDR4 modules.

Flash Memory

5GB (Dual boot OS protection)

Drive Bay

6 x 3.5-inch SATA 6Gb/s, 3Gb/s

Drive Compatibility

3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives

Hot-swappable

The following are not hot-swappable: M.2 SSDs, SSD cache drives, SSDs using PCIe expansion slots.

M.2 Slot

2 x M.2 2280 PCIe Gen3 x1 slots
The M.2 SSD is not included as standard.
M.2 SSD operations can easily generate excessive heat. It is recommended to install a heatsink (from QNAP or a third-party provider) on the M.2 SSD.

SSD Cache Acceleration Support

2.5 Gigabit Ethernet Port (2.5G/1G/100M) 2
5 Gigabit Ethernet Port (5G/2.5G/1G/100M)

Optional via a PCIe adapter

10 Gigabit Ethernet Port
Optional via a PCIe adapter

Wake on LAN (WOL)

Yes

Jumbo Frame

Yes


PCIe Slot

2


Slot 1

PCIe Gen 3 x4

Slot 2

PCIe Gen 3 x4

USB 3.2 Gen 2 (10Gbps) Port

3 x Type-A USB 3.2 Gen 2 10Gbps
1 x Type-C USB 3.2 Gen 1 5Gbps

IR Sensor

(QNAP RM-IR004)

HDMI Output

Optional via a PCIe adapter

Form Factor

Tower

LED Indicators

Status/Power, USB, LAN, Drive 1-6, M.2 SSD 1-2
